| उत्पत्ति के प्लेस: | चीन |
| ब्रांड नाम: | YUHONG |
| प्रमाणन: | ABS, GL, DNV, NK, PED, AD2000, GOST9941-81, CCS, ISO 9001-2008 |
| मॉडल संख्या: | एएसटीएम ए312 टीपी321, एएसटीएम ए312 टीपी321एच, गोस्ट 9941-81 12Х18Н10टी |
| न्यूनतम आदेश मात्रा: | 100kgs |
|---|---|
| मूल्य: | बातचीत योग्य |
| पैकेजिंग विवरण: | प्लास्टिक कैप के साथ प्लाई-वुडन केस / आयरन केस / बंडल |
| प्रसव के समय: | मात्रा पर निर्भर करता है |
| भुगतान शर्तें: | टी/टी, एल/सी |
| आपूर्ति की क्षमता: | 1500 टन प्रति माह |
| प्रमुखता देना: | ASTM A312 TP321 stainless pipe,high-temperature stainless steel pipe,1.4541 seamless steel pipe |
||
|---|---|---|---|
ASTM A312 TP321/321H is a grade of austenitic stainless steel seamless pipe renowned for its exceptional resistance to high temperatures and corrosion. The key differentiator of this grade is the addition of Titanium (Ti), which stabilizes the material against carbide precipitation during welding or exposure to high temperatures (450-850°C), thereby preventing intergranular corrosion. The "H" designation in TP321H indicates a higher carbon content variant, specifically engineered for applications where creep and stress rupture properties are critical at elevated temperatures.
This pipe is manufactured according to the ASTM A312/A312M standard, which covers seamless, welded, and heavily cold-worked austenitic stainless steel pipes intended for high-temperature and general corrosive service.
Primary Standard: ASTM A312 / A312M (Standard Specification for Seamless, Welded, and Heavily Cold Worked Austenitic Stainless Steel Pipes).
Common Designations:
UNS Number: S32100
Russian (GOST): 12Х18Н10Т
European (EN): 1.4541
Manufacturing Process: Seamless.
Typical Condition: Supplied in a heat-treated (annealed) condition.
Testing: Pipes undergo mandatory mechanical tests (tension, flattening) and non-destructive electric or hydrostatic tests. Supplementary tests for grain size and intergranular corrosion are also specified.
The TP321 grade is a Ni-Cr-Ti type austenitic stainless steel. Titanium binds with carbon preferentially over chromium, preventing the formation of chromium carbides at grain boundaries and ensuring excellent resistance to intergranular corrosion. It offers superior high-temperature strength and oxidation resistance compared to standard 304 stainless steel.
TP321 vs. TP321H: The main difference lies in the carbon content. TP321H has a higher minimum carbon requirement, which provides increased high-temperature strength, making it suitable for sustained service at temperatures where creep resistance is essential.
The following tables summarize the key requirements based on common standards.
Typical Chemical Composition (Weight %):
| Element | TP321 / 321H Typical Range | Notes |
|---|---|---|
| Carbon (C) | ≤ 0.08 (TP321); Higher for 321H | Key difference between grades. |
| Chromium (Cr) | 17.0 - 19.0 | Provides oxidation & corrosion resistance. |
| Nickel (Ni) | 9.0 - 12.0 | Stabilizes the austenitic structure. |
| Manganese (Mn) | ≤ 2.0 | - |
| Silicon (Si) | ≤ 1.0 | - |
| Phosphorus (P) | ≤ 0.045 | - |
| Sulfur (S) | ≤ 0.030 | - |
| Titanium (Ti) | ≤ 0.70 | Stabilizing element for intergranular corrosion resistance. |
| Iron (Fe) | Balance | - |
Room Temperature Mechanical Properties:
| Property | Typical Value (Annealed Condition) | Standard / Reference |
|---|---|---|
| Tensile Strength | ≥ 515 MPa (75 ksi) | ASTM A312 |
| Yield Strength (0.2% Offset) | ≥ 205 MPa (30 ksi) | ASTM A312 |
| Elongation (in 2 inches or 50 mm) | ≥ 40% | ASTM A312 |
TP321/321H seamless pipes are specified for demanding environments across various industries:
Petroleum, Chemical & Process Industries: Heat exchangers, condenser tubes, furnace components, and process piping handling corrosive media.
Power Generation: Boiler superheater and reheater tubes, heat exchanger piping in power plants, and flue gas desulfurization (FGD) systems.
High-Temperature & Exhaust Systems: Engine exhaust pipes, industrial exhaust systems, and gas turbine parts.
Oil & Gas: Refinery piping, offshore platform equipment, and underwater systems.
Other Applications: Components for nuclear reactors (specific grades), pharmaceutical processing equipment, and automotive industry.
